Cable termination is the device fitted to the end of a cable to ensure electrical connection with other parts of the
system and to maintain the insulation up to the point of connection. Including indoor and outdoor types.
What is the difference between indoor and outdoor terminations?
The creepage distance over the surface of the terminations is longer for outdoor terminations than for indoor
terminations. This can be achieved by a greater length and by the use of sheds.
What is the function of a Termination?
Restore the insulation and provide stress control at the semicon cut-off point of the cable (which is connected toequipment with a cable lug). A termination is an unscreened, not safe to touch connection. Minimum clearance distances must be respected.
What is a cable joint?
Cable joint is the accessory making a connection between two cables to form a continuous circuit.
What is the function of a joint?
The function of a joint is to connect two cables to each other. The several functions are connecting the conductor,
providing stress control at the semi-con cut-off point of the cable, keeping the electrical field inside of the joint,
reinstalling the insulation and providing a screen connection.
What is separable connector?
Separable connector is a fully insulated termination permitting the connection and the disconnection of a cable to
other equipment. Including screened and unscreened types.
What is the function of a separable connector?
To connect MV cable to equipment, such as transformers, switchgear, motors and generators.
How many types of interfaces connectors do you have?
We have type A, B, C, D, E, F interface connectors. Type A interface connector is elbow shape, and other interface
connectors are T shape with a removable back plug.
